BL2202 ECP – 28mm ali latch, inside paddle handle with holdback & ECP coding chamber

The BL2202 ECP is one of our entry level models making up the Easicode Pro range. Fully mechanical and with a simplistic design, the model allows quick and easy code changing without requiring removal off the door. The BL2202 ECP comes with a holdback function should

Fitted with a 28mm Ali latch, this unit is an ideal solution for aluminium and narrow stile doors.

£103.00 Excl. VAT - £123.60

Description

The BL2202 ECP is one of our entry level light duty locks from the BL2000 Series. Fully mechanical and with a simple design, the model provides automatic locking until such a time that the correct code is entered.

Separating the Easicode Pro range from the conventional locks is the patented “On the door” code change method. With ECP, the long and drawn out method of removing tumblers from the back of the keypad is over, cutting down what could be a 10-15 minute job to one that takes only seconds.

The keypad itself has over 4,000 combinations, is cycle tested to 50,000 operations and is suited for internal doors where unauthorized entry is risk.

This particular variant comes fitted with a specialist 28mm ali latch. This is specifically designed for narrow stile aluminium doors and features hardened steel pins with a separate anti-thrust pin.

The BL2202 ECP comes with a holdback function, allowing the door to be locked open for situations that demand free movement.

This keypad is ideal for light duty, access control solutions and is suited for internal aluminium or narrow stile doors.


Additional information

Application

Timber Door, Aluminium Door, Composite Door

Colour

Satin Chrome

Internal / External

Internal

Latch

28mm Ali Latch

Section

Aluminium Door Locks, Narrow Stile Door Locks

Duty Rating

Light duty

Handle Type

Knob turn

Latch type

Ali latch
